Butterfly Valve

Overview

“Nilon” Series Butterfly Valve are the best used in the industry, the range varies from wafer type lift & swing type non return valve Nilon swing check valves are provided with properly guided swing disc through a hinge. The hinge and swivel disc are connected maintaining sufficient flexibility for smooth and efficient sealing. “Nilon” Series non return valve are available with metal-to-metal sealing for high temperature and pressure; soft sealing for pneumatic and vacuum applications. Designed to ensure full flow, efficient function and minimum pressure drop across the valve.

Download Catlouge OF BALL VALVE PRODUCT
Company Brochure pdf

TECHNICAL SPECIFICATION

Manufacturing Standard BS 5155 / API 609, AWWA C 504
Testing Standard BS 6755 / API 598
Pressure Class 150# to 1500#, PN10 to PN16
Material of Construction Cast
  • Cast Iron IS 210, Gr. FG 200/220/260, Cast Carbon Steel ASTM 216 Gr. WCB
  • Cast Steel ASTM 352, Gr. LCB & LCC
  • Cast Stainless Steel ASTMA 351 CF8/CF3/CF8M/CF3M
  • Alloy 20 ASTM A351 Gr CN7M
  • Forged Carbon Steel ASTM A 105
  • Duplex and Hastelloy
    		•
    Design Type Slim seal, Wafer Type, Double flanged Type
    Size Range 1.1⁄2” Through 48”
    End Connection Wafer Type/ Flanged End
    Engineering Options Lever operated, Gear operated, Pneumatic/ Electrical Actuator operated
